9
NS-WC45BK7
www.insigniaproducts.com
2 Remove top hinge, then lift the door up off of bottom hinge and place it
on a padded surface to prevent scratching.
3 Remove the three button plugs from the upper left corner of the cabinet
and transfer them to the holes on the opposite side. Be sure to press the
button plugs firmly into the holes.
4 Remove the three screws that hold the bottom hinge to lower portion of
cabinet, then remove the three button plugs from lower left corner and
transfer them to the holes where the bottom hinge was just removed.
To Next Page
