Inspire CG3 - Assembly Step 3

Pg. 12 V12192022_CG3.1PK
STEP 3
A. Slide two Shroud Mount Bars (34) into one of the Outer Fabric Shrouds (27).
B. Install two Shroud Mount Bars (34) using four M8 x 15mm Allen Bolts (19) and M8 Washers (25) to the Right
Main Frame (1).
C. Repeat the steps above for the Left Main Frame (2).
1
2
19
19
25
25
34
34
27
19
19
25
25
34
34
27
