Inspire CG3 User Manual

Pg. 13
V12192022_CG3.1PK
STEP 4
A. Attach the Adjustment Handle (36) to the Left Lock Switch on the Pulley Carriage and secure it with one M5 x 8 mm Allen
Bolt (15). Repeat the same procedure to install the other side.
B. Connect the 2-Ring D-Handle (24) to the Cable on the Right Main Frame (1) with a Spring Clip (39) . Repeat the same
procedure to install the other side.
C. Lift the Adjustment Handle (36) and slide the Pulley Carriage up or down to the selected level. Release the Handle to lock
the Pulley Carriage in position.
D. Hang the Rope (20) and the Chin Up Belt (30) on the hook of the Upper Cross Brace (5).
E. Store the Curl Bar (22) and Straight Bar (23) onto the Hanger Bracket behind the Upper Cross Brace (5) as shown.
1015,00
20
39
24
39
24
23
22
15
36
30
25
