Inspire SCS-202 User Manual

Note: Two tabs to rear
Rear Cross Brace
Step 5
2 - M8 x 20 Hex Bolts
2 - M10 Flat Washers
Pull-Up Bar Cross Brace
Step 6
2 - M8 x 20 Hex Bolts
2 - M8 Flat Washers
Step 5: Attach the Pull-Up Cross Brace to top of front Two (M8 x 20 Hex Bolts)
Main Uprights using: Two (M8 Flat Washers)
(Finger Tighten Only)
Step 6: Attach the Rear Cross Brace to the top of Two (M8 x 20 Hex Bolts)
the rear Main Uprights using: Two (M8 Flat Washers)
Assure the two tabs in the center of the Rear Cross Brace are facing towards the back of the
machine.
(Finger Tighten Only)
Page 8
