Weight Rack mounting tabs
Main Upright
Step 2
4 M10 x 105 Hex Bolts
8 M10 Flat Washers
4 M10 Locknuts
Step 2: Attach two Main Uprights to the rear of the Left and Right Four (M10 x 105 Hex Bolts)
Right Base Beams (orient all Uprights with the four Weight
Eight (M10 Flat Washers)
Rack mounting tabs toward the middle of the machine
Four (M10 Locknuts)
and near the top) using:
(Finger Tighten Only)
Page 6
