Insportline DEVRON - Brake System; Brake Adjustment Principles; Brake Adjustment Steps; Brake Pad Replacement

13
BRAKES
INFORMATION ABOUT THE BRAKE ADJUSTMENT
The brakes must be adjusted so that when you squeeze the handle to the half of the stroke (Fig. 1),
the whole braking surface of the brake pads bear against the rim (Fig.2).
BRAKE ADJUSTMENT
If you feel that your brakes are not to your taste, you can adjust your brakes with screw cable tension.
That is if in your brake lever (Fig. 3).
Tightening the screw cable inward relax a little cable so you spread the pads and the loosening
outward, you stretch the cable so the pads closer to the rim.
BRAKE PADS REPLACEMENT
The brake pads should be replaced when the grooves are no longer visible (Fig. 4).
