FOR USE BY QUALIFIED PERSONNEL ONLY
Installation
256-S MODEL, 120 VOLT
Use a separate 15 Amp AC circuit.
Only industrial extension cords with
proper wire size should be used: size
16/3 wire for distances up to 25
feet, and size 14/3 for distances up
to 50 feet.
256-N MODEL, 230 VOLT
Use a designated 12 Amp AC circuit.
Only industrial extension cords with
proper wire size (2.5 mm
2
) shall be
used.
IMPORTANT
The appliance must be plugged into
a proper receptacle of the proper
size and rating. Equally important,
the line voltage must be able to
accommodate this appliance as well
as other appliances operating on this
circuit.
Specifications
Voltage
120 Volts AC
50/60 Hertz
Model
256
-
S
120 V
1750 Watts
14.6 Amps
Voltage
230 Volts AC
50/60 Hertz
Model
256
-
N
230 V
2200 Watts
9.6 Amps
Machine Weight
(Dry)
107 lbs 48.5 kg
Shipping Weight
(Dry)
122 lbs 55.3 kg
Degree of Protection
The IP (Ingress Protection) rating of this machine
according to IEC 60529 is:
IP54 = IP
1
st
Digit = 5 (Dust Protected)
2
nd
Digit = 4 (Splashing Water)
1
st
Digit
Protection from
solid objects
2
nd
Digit
Protection from
moisture
0 Not protected 0 Not protected
1
Objects greater
than 50 mm
1 Dripping water
2
Objects greater
than 12 mm
2
Dripping water
when tilted up
to 15°
3
Objects greater
than 2.5 mm
3 Spraying water
4
Objects greater
than 1 mm
4 Splashing water
5 Dust protected 5 Water jets
6 Dust tight 6 Heavy seas
-- --- 7
0.15 m – 1 m
immersion
-- --- 8
+1 m
submersion
NOTE:
IEC 60529 does not specify sealing effectiveness against
the following: mechanical damage of the equipment; the
risk of explosion; certain types of liquid conditions, e.g.
those that are produced by condensation; corrosive
vapor; fungus; vermin.
