CONTENTS & INTRODUCTION 2
SAFETY INFORMATION 2
ENVIRONMENTAL INFORMATION & DELIVERY CHECKLIST 3
TECHNICAL SPECIFICATION 3
INSTALLATION 4 - 5
OPERATION 5 - 6
REGULAR DAILY USE 6
ECO MODE 6
LCD & PROGRAM MODE 6 - 7
CLEANING 7
MAINTENANCE, SPARES & SERVICE INFORMATION 8
SERVICE WARNINGS & FAULT DIAGNOSTICS 8 - 9
FULL PROGRAM MENU 10
SERVICE/TECHNICAL SUPPORT/GUARANTEE 11
Introduction
Dear Customer,
Congratulations on the purchase of your
Instanta machine.
Your new boiler is designed to give years
of trouble-free service, provided that the
instructions contained in this manual are
followed.
All new series Instanta products are energy
ef cient, simple to operate and easy to service.
Find out more about Instanta products at
www.instanta.com
Safety Information
Please read the following carefully
before switching on this appliance:
A competent installation engineer should install
this appliance in accordance with the installation
instructions for this appliance and all relevant
local and national standards including the
following:
• Health and Safety at Work Act
• IEE regulations
• Local and national building regulations
• BS Codes of practice
• Water supply regulations
Your new water boiler is designed to provide
a constant source of near-boiling water for the
preparation of hot drinks.
Caution Safety: All personnel must be
provided with suf cient and appropriate
training in the safe use of this appliance.
• In line with Health and Safety requirements
we recommend that a risk assessment be
carried out after the boiler has been
installed.
• A warning notice, displayed next to the
machine, is often helpful in notifying users
that the appliance contains and dispenses
near-boiling water.
• Inform users that certain surfaces will
become hot (especially the draw off tap).
Care should be taken to avoid potential
injury from burns and scalding whilst
operating this appliance.
• The unit must be earthed.
• Always disconnect the unit from the power
supply before servicing
Environmental
(Information on Disposal for Users of Waste
Electrical & Electronic Equipment)
The “crossed out wheelie bin” symbol on
this product means that discarded electrical
and electronic products should not be mixed
with general waste. Disposing of the product
correctly will help to save valuable resources
and prevent any potential negative effects
on human health and the environment which
could otherwise arise from inappropriate waste
handling. For proper treatment, recovery and
recycling of end-of-life products, please contact
your dealer or supplier for further information,
or local authority for details of your nearest
designated collection point.
Model Width Depth Height Power
Rating
Rapid
Draw-off
Weight
(empty)
Weight
(full)
Water
Inlet
Pressure
mm mm mm kW Litres KG KG Bar
WM3 332 210 452 3 3 7.3 12.5 2 to 7
WM3SS 314 215 414 3 3 9.4 14.5 2 to 7
WM7 350 220 498 3 7 8.4 18.6 2 to 7
WM7SS 320 225 456 3 7 9.5 19.7 2 to 7
WM15-3SS 350 250 545 3 15 10.7 29 2 to 7
WM15-6SS 350 250 545 6 15 10.9 29.2 2 to 7
WM25SS 410 304 596 3 or 6 25 17.1 48 2 to 7
Technical Specifi cation
Outer casing is constructed from either impact
resistant plastic or Type-304 stainless steel.
The tank is made from Type-304 stainless steel
and the internal baf e-plates [for condensing
steam within the tank, are made from Type-316
stainless steel. The tank is fully insulated with
high-temperature polystyrene.
The appliance has electronic control of the main
functions. This means that the heating, lling
and temperature are controlled precisely within
given parameters.
Checklist
Before starting installation check that you have
the following parts:
1. Main Boiler Unit
2. Boiler Case
3. Paper Mounting Template
4. Fitting Kit (screws & wall-plugs etc.)
5. Instruction Booklet
