EXTEND AND SECURE THE TOW BAR
❶ Place the trailer on its side with the tow bar facing up.
❷ Remove the locking pin from the tow bar bracket. Figure 3.6
❸ Rotate the tow bar unl it rests on the front end of the frame.
❹ Insert the locking pin through both the bracket and tow bar.
❺ Slide the metal safety loop on the end of the locking pin.
Check that it is securely in place. Figure 3.7
InStep Sync Trailer 8
Figure 3.7Figure 3.6
2
3
4
5
