4 Trailer Aachment
Use of the trailer without the safety strap aached to the
bicycle may result in serious injury or death. Always aach the
safety strap to the bicycle when using the trailer.
Important! This secon provides instrucons for aaching the
trailer coupler to the bicycles REAR WHEEL with a hub nut or quick
release lever. The coupler aaches to most bicycles.
To ensure secure aachment of the coupler to the bicycle, be
sure the thread of the rear axle extends at least 2 mm’s from
the hub nut before proceeding to the next step. Figure 4.1
Using a wrench, remove the hub nut and washer from the
bicycle’s back wheel. Figure 4.2
Place the tab washer on the axle. Fit the tab into the slot on
the bicycle frame dropout. Note: If your bicycle frame doesn’t
have a slot in the drop out, rotate the tab to t into the axle
slot. Figure 4.3
Washer
Hub nut
3
2
Slot
Tab
washer
1
Figure 4.1
Figure 4.2
Figure 4.3
2 mm
2 mm
2 mm
WARNING!
11 InStep Sync Trailer
