❼ Slide the tow bar into the open end of the coupler.
Important! Ensure the coupler is completely in line with the
tow bar. This reduces stress on the tow bar. Figure 4.10
❽ Insert the locking pin into the hole on the top of the coupler.
❾ Slide the safety loop over the end of the lock pin. Figure 4.11
Important! Ensure the loop of the safety pin is facing away
from the wheel to prevent possible fricon against the wheel
and spokes of the bicycle.
Figure 4.10
Figure 4.11
7
8
9
9
15 InStep Sync Trailer
