InStep Take 2 - Attachment with Quick Release

ATTACHMENT WITH QUICK RELEASE
❶ Release the quick release lever, skewer and remove the nut
and spring from the opposite side of the wheel.
❷ Remove the axle skewer and spring. Leave the wheel in place.
Figure 4.7
❼ Slide the tow bar into the open end of the coupler.
Important! Ensure the coupler is completely in line with the
tow bar. This reduces stress on the tow bar.
❽ Insert the locking pin into the hole on the top of the coupler.
Slide the safety loop over the end of the lock pin.
Important! Ensure the loop of the safety pin is facing away
from the wheel to prevent possible fricon against the wheel
and spokes of the bicycle. Figure 4.6
Figure 4.6
8
Figure 4.7
Skewer
Inner
Spring
Quick
release lever
Nut
Outer
spring
2
Quick release
lever and spring
8
7
13 Take 2 Trailer
