InStep Take 2 - Disassembly and Storage; Removing Tow Bar from Bicycle

WARNING!
• There are pinch points between the sidewalls and the frame
of the trailer that may cause injury.
• Always fold or unfold the trailer slowly and with cauon.
• Keep children clear when folding or unfolding the trailer.
REMOVE THE TOW BAR FROM THE BICYCLE
❶ Remove the child from the passenger compartment.
❷ Unfasten the clip on the safety strap from the tow bar ring,
and unwrap it from the bicycle frame. Clip the strap back onto
the D-ring of the tow bar. Figure 6.1
Figure 6.1 Figure 6.2
❸ Remove the locking pin from the tow bar coupler. Figure 6.2
❹ Remove the tow bar from the coupler.
❺ Insert the locking pin through the end of the tow bar and
secure it with the safety loop.
❻ If desired, leave the coupler on the bicycle wheel hub for
future use. It is not necessary to remove when storing.
4
3
1
2
Take 2 Trailer 22
6 Disassembly and Storage
