2-23
Accessory Mounting Dimensions
Product Support: www.instron.com
Figure 2-10. 5984 and 5985 Moving Crosshead Mounting Dimensions
280
130
65
140
241
482
45
90
38
75
M10 x 25 Deep
(10X)
Ø22 Thru
Ø31.75 x 28
M16 x 35 Deep
(8X)
Ø100
Front of frame
(4X)
Deep Counterbore
Ø60 x 3 Deep
Topside of moving crosshead
280
140
90
45
Underside of moving crosshead
Ø60 x 3 Deep
M10 x 25 Deep
(10X)
Ø100
Ø51 Thru
