Spare Parts
Product Support: www.instron.com
5984 and 5985 Frames
5988 Frame
Table 5-3. 5984 and 5985 Ancillary Parts
Description
Part
Number Quantity Purpose
Cable Ethernet Cat5E 10ft
Crossover
144-1-1052 1 Connects the frame controller to the
computer
Hex wrench key set,
1.5 to 10 mm
80-1-1011 1 Tools for maintaining the frame and
installation of accessories
Fuse, 2A Slo-blo, 6.3 x 32mm
glass
27-2-13 1 Protection from electrical surges
Cable clip, 6-12 mm 11-6-60 4 Secures cables to the frame
Nut, M5 T-slot clip 52-59-1011 4 Installing accessories onto the column
cover
Accessories slot T-nut T1697-1307 4 Installing accessories onto the column
cover
3 MTS Ground cable A712-213 1 Used to connect the frame to a
suitable ground where the mains
power supply is not grounded
Locating ring T1208-1147 2 Locating ring adapter - converts
60mm to 40mm for base
Locating ring type 2 T1335-1052 2 Locating ring for load cell- 60mm
diameter for M48 thread
Screw, M20 x 200 201R374 4 Attaches load cell to crosshead
Tool socket driver, 17mm key 80-3-51 1 Tool for removing M20 screws
Tool spanner, open 19 mm a/f 80-51-1003 1 Leveling the load frame
Table 5-4. 5988 Ancillary Parts
Description
Part
Number Quantity Purpose
Cable Ethernet Cat5E 10ft
Crossover
144-1-1052 1 Connects the frame controller to the
computer
Hex wrench key set,
1.5 to 10 mm
80-1-1011 1 Tools for maintaining the frame and
installation of accessories
