Chapter: Requirements and Specifications
2-20 M10-16250-EN
Base Beam
Figure 2-6. 5982 Base Beam Mounting Dimensions
150 150 150
75
150
75
90
45
280
140
M30 x 2-6H
40 Deep, LH
Ø40 x 3 Deep
M16 x 30 Deep
(8X or 12X for extra wide)
M10 x 25 Deep
(10X)
Front of frame
Ø100
150
150
Figure 2-7. 5984 and 5985 Base Beam Mounting Dimensions
150 150 150
75
150
75
90
45
280
140
Ø60 x 3 Deep
M16 x 30 Deep
(8X or 12X for extra wide)
M10 x 25 Deep
(10X)
Front of frame
Ø100
M48 x 2-6H
52 Deep, LH
150
150
