Chapter: Maintenance
5-10 M10-16250-EN
Spare Parts
Ancillary Parts - Frames with a Single Test Space
The following sections list the parts supplied with each of the 5980 Series load frames.
5982 Frame
Table 5-2. 5982 Ancillary Parts
Description
Part
Number Quantity Purpose
Cable Ethernet Cat5E 10ft
Crossover
144-1-1052 1 Connects the frame controller to the
computer
Hex wrench key set,
1.5 to 10 mm
80-1-1011 1 Tools for maintaining the frame and
installation of accessories
Fuse, 2A Slo-blo, 6.3 x 32mm
glass
27-2-13 1 Protection from electrical surges
Cable clip, 6-12 mm 11-6-60 4 Secures cables to the frame
Nut, M5 T-slot clip 52-59-1011 4 Installing accessories onto the column
cover
Accessories slot T-nut T1697-1307 4 Installing accessories onto the column
cover
3 MTS Ground cable A712-213 1 Used to connect the frame to a
suitable ground where the mains
power supply is not grounded
Locating ring T1335-1048 1 Locating ring for base - 40mm
diameter for M30 thread
Screw, M10 x 160 201R250 6 Attaches load cell to crosshead
Compression spring
3/4OD x 2 in length
66-4-5 1 Removes slack on lower grips with no
checknut
Tool spanner, open 19 mm a/f 80-51-1003 1 Tool for tightening lock nuts on load
string
Retainer clip for 0.5 in diameter pin T1223-1053 2 Prevents the grip coupling pin from
sliding out during testing
Retaining pin, grip coupling T29-515 2 Secures the grip coupling
