INTARCON MCV-N - MCV Series R134 a Technical Data

10
(1) Cooling capacity under cold room temperature of 0 ºC (32 ºF) and ambient temperature of 35 ºC (95 ºF).
(2) Total absorbed power by compressor and fans under nominal condition (axial version).
(3) As defined by RD138/2011. IF-01.
(4) Maximum absorbed current even beyond compressor operation limits (axial version).
MCV series R134a
0010 0015
1015
1026
1033
2033
2053
3053
3074
3108
Cooling capacity
Cooling capacity (1) (W) 610 794 972
1281
1454
1790
2153
2489
3239
3927
Absorbed power (2) (W)
430 530 570
810
920
1090
1460
1510
1890
2480
COP performance 1,42 1,50 1,71
1,58
1,58
1,64
1,47
1,65
1,71
1,58
Installed power (3) (kW) 0,59 0,83 0,83
1,22
1,44
1,44
2,2
2,2
2,9 4,4
Condenser fan
NY version
Nominal air flow rate (m3/h) 375 575 950 1150
Type
Axial
Power (W) - r.p.m 85 W @ 1300
2x 85 W @
1300
2x 70 W @ 1300
Condenser fan
CY version
Nominal air flow rate (m3/h) 375 575 950 1150
Available static pressure (Pa) 120
Type Centrifugal
Power (W) 180 W 220 W 2x 200W
2x 200W
Evaporator fan
Nominal air flow rate (m3/h) 300 500 950 1300
Range (m) 3 4
Type Axial
Power (W) - r.p.m 47W @ 2500 62W @ 2600
2x 62W @
2600
2x 70W @ 2600
Compressor
Type Hermetic reciprocating
Swept volume (m3/h) 2,08 3,18 3,18
4,51
5,69
5,69
9,26
9,26
12,92
18,74
Nominal discharge pressure (bar rel.) 10
Nominal suction pressure (bar rel.) 1
Nominal power (CV) 3/8 1/2 1/2
3/4
1 1
1 1/2
1 1/2
2 5
High pressure switch
Type ACB
Brand Danfoss
Model 061F6147
Cut out (bar rel.) 20
Max. absorbed
intensity (A)(4)
230 V / I ph / 50 Hz 5,9 6,9 7,0
10,7
10,9
11,17
13,77
14,19
19,74
-
400 V / III ph / 50 Hz Not available 18,5
Starting-up intensity
(A)
230 V / I ph / 50 Hz 13,2 20,7 20,7
27,0
30,0
30,0
46,0
46,0
55,0
-
400 V / III ph / 50 Hz Not available 65
Refrigerant
Type R-134a / Group A1 / GWP-100: 1430
Load (kg) 0,56 0,62 0,64
0,64
0,70
0,90
0,90
1,30
1,20
1,40
Dimensions
Length (mm) 306+250 340+514 340+514
365+514
Wide (mm) 420 400 620 735
Height (mm) 683 880 920 940
Weight (kg) 36 38 60 69 70 88 89 117
114 116
Sound pressure level db(A) 28 29 29 34 34 35 39 38 41 43
