10. MCR SERIES TECHNICAL FEATURES
(1) Cooling capacity under cold room temperature of 0 ºC (32 ºF) and ambient temperature of 35 ºC (95 ºF).
(2) Total absorbed power by compressor and fans under nominal condition (axial version).
(3) As defined by RD138/2011. IF-01.
(4) Maximum absorbed current even beyond compressor operation limits (axial version).
MCR Series R404A
0008
0010
0012
1010
1012
1014
1016
1018
1024
2024
2026
2034
Cooling
capacity
Cooling capacity (1) (W) 612 738 838 799 930 1087
1194
1378
1478
2020
2223
2527
Absorbed power (2) (W) 470 580 650 652 672 811 880 1038
1201
1319
1425
1903
COP performance 1,30 1,27 1,29 1,23 1,38 1,34 1,36 1,33 1,23 1,53 1,56 1,33
Installed power (3) (kW) 0,53 0,73 0,86 0,75 0,82 0,98 1,10 1,38 1,68 1,68 1,89 2,63
Condenser
fan
NF version
Nominal air flow rate (m3/h) 375 575 1150
Type Axial
Power (W) - r.p.m 85 W @ 1300 rpm 120W @ 1300 rpm
Condenser
fan
CF version
Nominal air flow rate (m3/h)
-
575 1150
Available static pressure (Pa) 45
Type Centrifugal
Power (W) 45 W @ 1300 rpm 105 W @ 1300 rpm
Evaporator
fan
Nominal air flow rate (m3/h) 300 600 1150
Range (m) 3 4
Type Axial
Power (W) - r.p.m 47@ 2500 rpm 62W @ 2600 rpm
2x 62W @ 2600
rpm
Compressor
Type Hermetic reciprocating
Swept volume (m3/h) 1,16 1,54 1,79 1,64 1,96 2,32 2,65 3,18 4,21 4,21 4,52 6,01
Nominal discharge pressure (bar
rel.)
20
Nominal suction pressure (bar
rel.)
3,40
Nominal power (CV) 1/3 3/8 1/2 3/8 1/2 1/2 5/8 3/4 1 1 1 1/4
1 1/2
High pressure
switch
Type ACB
Brand Danfoss
Model 061F8175
Cut out (bar rel.) 28
Max.
Absorbed
intensity(4)(A)
230 V / I ph / 50 Hz 4,5 5,9 6,7 5,1 6,1 6,7 7,6 8,9 11,1 11,6 12,0 16,6
400 V / III ph /50 Hz Not available 5,4 6,2
Starting up
intensity (A)
230 V / I ph / 50 Hz 16,3 18,8 20,2 16,9 17,9 20,9 23,5 30,9 34,4 34,9 33,4 46,4
400 V / III ph /50 Hz
Not available 19,4 24,4
Refrigerant
Type R-404A / Group L1 / GWP-100: 3922
Load (kg) 0,50 0,50 0,50 0,80 0,70 0,80 0,83 0,76 0,86 1,10 1,05 1,10
Dimensions
Length (mm) 790 850 850
Wide (mm)
600 665 835
Height (mm) 480 385+189 468+189
Weight (kg) 62 64 65 73 73 73 82 83 83 98 99 99
Sound pressure level db(A) 30 30 30 32 32 32 34 35 35 36 38 40
