LABELING SYMBOLS GLOSSARY
Symbol
Symbol Ref.
Number
Standard Description Title
Table D.1, 24 IEC 60601-1:2005+A1:2012
Medical electrical equipment -
Part 1: General requirements
for basic safety and essential
performance
Dangerous Voltage
5140 ISO 7000:2014
Graphical symbols for use on
equipment – Registered symbols
Non-ionizing Electromagnetic
Radiation
- Proprietary - Irrigator Connection
Table D.3, 2
4.2
IEC 60601-1:2005+A1:2012
IEC 60529:1989+A1:1999+
A2:2013
Medical electrical equipment -
Part 1: General requirements
for basic safety and essential
performance.
Degrees of Protection Provided
by Enclosures (IP Code).
Protection against solid foreign
objects of 12.5 mm diameter and
greater
When a characteristic numeral is
not required to be specified, it is
replaced by the leer “X”
0623 ISO 7000:2014
Graphical symbols for use on
equipment – Registered symbols
This Way Up
5.3.1 ISO 15223-1:2016
Medical Devices - Symbols to be
used with medical device labels,
labelling and information to be
supplied
Fragile, Handle with Care
5.3.4 ISO 15223-1:2016 Keep Dry
5.3.7 ISO 15223-1:2016 Storage Temperature Limit
5.3.8 ISO 15223-1:2016 Storage Humidity Limit
5.3.9 ISO 15223-1:2016 Storage Pressure Limit
1050hPa
500hPa
-40
o
C
-40
o
F
60
o
C
140
o
F
15%
85%
IP2X
