En-23
Specifications
Amplifier Section
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE)
3.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
1 V/470 Ω (PRE OUT)
1 V/470 Ω (SUBWOOFER PRE OUT)
100 mV/2.2 kΩ (ZONE2/ZONE3 LINE OUT)
1 V/2.2 kΩ (ZONE2/ZONE3 PRE OUT)
Rated XLR Output Level and Impedance
2 V/440 Ω(PRE OUT)
Phono Overload
70 mV (MM 1 kHz 0.5% Direct)
Frequency Response
5 Hz - 100 kHz/+1 dB, –3 dB (Direct mode)
Tone Control Characteristics
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio
77 dB (LINE, IHF-A)
51 dB (PHONO MM, IHF-A)
Video Section
Signal Level
1.0 Vp-p/75 Ω (Component Y)
0.7 Vp-p/75 Ω (Component Pb/Cb, Pr/Cr)
1.0 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, –3 dB
Corresponding maximum resolution
480i/576i (Component to HDMI)
720p/1080i (Component to Component)
Tuner Section
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz (North American)
87.5 MHz - 108.0 MHz, RDS (Others)
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel
40
Network Section
Ethernet LAN
10BASE-T/100BASE-TX
General
Power Supply
120 V AC, 60 Hz (North American)
220 - 240 V AC, 50/60 Hz (Others)
Power Consumption
0.5 A (North American)
45 W (Others)
0.15 W (Stand-by, North American)
0.2 W (Stand-by, Others)
2.7 W (Network Standby)
95 W (No-sound)
Dimensions (W × H × D)
435 mm × 199 mm × 416 mm
17-1/8" × 7-13/16" × 16-3/8"
Weight
12 kg (26.5 lbs.)
･ HDMI
Input
IN1 (BD/DVD, HDCP2.2), IN2 (CBL/SAT, HDCP2.2), IN3 (STRM BOX,
HDCP2.2), IN4 (PC, HDCP2.2), IN5 (GAME1, HDCP2.2), IN6 (GAME2),
IN7, AUX INPUT HDMI (front)
Output
OUT MAIN, OUT SUB/ZONE2
Video Resolution
4K 60 Hz (RGB/YCbCr4:4:4/YCbCr4:2:2, 24bit)
Audio Format
Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Dolby Digital, DTS:X,
DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-
ES, DTS, DTS Express, Multichannel PCM (up to 8ch)
Supported
3D, Audio Return Channel, Deep Color, x.v.Color™, LipSync, CEC, 4K,
Extended Colorimetry (sYCC601, Adobe RGB, Adobe YCC601), Content
Type, 3D Dual View, 21:9 Aspect Ratio Video Format
･ HDBaseT
OUT (
)/IN (HDMI)
＊ 3G bps or less for 4K (use a CAT 5e or better cable, 70 m or less in length)
･ Video Inputs
Component
IN1 (BD/DVD), IN2 (GAME2)
Composite
IN1 (GAME1), IN2 (CBL/SAT), IN3 (STRM BOX)
･ Video Outputs
Component
OUT
Composite
OUT
･ Audio Inputs
Digital
OPTICAL 1 (STRM BOX), 2 (CD), 3 (TV)
COAXIAL 1 (BD/DVD), 2 (CBL/SAT)
Analog
BD/DVD, GAME2, PC, GAME1, CBL/SAT, TV, CD, PHONO
Balance
BALANCE L/R
･ Audio Outputs
Analog
PRE/LINE OUT (ZONE2/ZONE3)
PRE OUT (FRONT L/R, CENTER, SURROUND L/R, BACK L/R, 2
SUBWOOFER, HEIGHT L/R)
Speaker Outputs
PRE OUT(FRONT L/R, CENTER, SURROUND L/R, BACK L/R,
SUBWOOFER 1, SUBWOOFER 2, HEIGHT or Bi-AMP L/R)
Phones
PHONES (Front, ø 6.3)
･ Others
Setup Mic 1 (Front)
RS232 1
RI REMOTE CONTROL 1
USB 1 (Ver. 1.1, 5 V/1 A)
Ethernet 1
IR IN 2 (A/B)
IR OUT 1
12V TRIGGER OUT 3 (A: 100 mA, B: 25 mA, C: 25 mA)
Multi language on-screen display
(North American) English, German, French, Spanish, Italian, Dutch,
Swedish, Chinese (
)
(Others) English, German, French, Spanish, Italian, Dutch, Swedish,
Russian, Chinese (
)
＊ OSD are not displayed when input is "NET". Operate by confirming
the display on the main unit.
Specifications and features are subject to change without notice.
