Advanced Settings
44
12V Trigger B Setup
You can enable power link operation when you connect the unit and the external devices
equipped with 12V trigger input jack. When the desired input is selected, power link
operation will be activated with a control signal of maximum 12V/25mA output from the 12V
trigger output jack.
Setting Item Default Value Setting Details
Delay 1sec Set after how many seconds the 12V trigger
output will occur in response to the unit's
operation. As some devices cause a large
current when they turn on, delay the output if
such devices are connected. Select a value
between "0sec" to "3sec".
BD/DVD Main/
Set the 12V trigger output setting to each
input. Setting should be made for each 12V
trigger out jack.
"Off": No output
"Main": Will be output when selected as input
source of main room playback
"Zone 2": Will be output when selected as
input source of Zone 2 playback
"Main/Zone 2": Will be output when selected
as input source of main room or Zone 2
playback
"Zone 3": Will be output when selected as
input source of Zone 3 playback
"Main/Zone 3": Will be output when selected
as input source of main room or Zone 3
playback
"Zone 2/Zone 3": Will be output when selected
as input source of Zone 2 or Zone 3 playback
"Main/Zone 2/Zone 3": Will be output when
selected as input source of main room, Zone
2 or Zone 3 playback
Setting Item Default Value Setting Details
CBL/SAT Main/
Set the 12V trigger output setting to each
input. Setting should be made for each 12V
trigger out jack.
"Off": No output
"Main": Will be output when selected as input
source of main room playback
"Zone 2": Will be output when selected as
input source of Zone 2 playback
"Main/Zone 2": Will be output when selected
as input source of main room or Zone 2
playback
"Zone 3": Will be output when selected as
input source of Zone 3 playback
"Main/Zone 3": Will be output when selected
as input source of main room or Zone 3
playback
"Zone 2/Zone3 ": Will be output when selected
as input source of Zone 2 or Zone 3 playback
"Main/Zone 2/Zone 3": Will be output when
selected as input source of main room, Zone
2 or Zone 3 playback
STB/DVR Main/
Set the 12V trigger output setting to each
input. Setting should be made for each 12V
trigger out jack.
"Off": No output
"Main": Will be output when selected as input
source of main room playback
"Zone 2": Will be output when selected as
input source of Zone 2 playback
"Main/Zone 2": Will be output when selected
as input source of main room or Zone 2
playback
"Zone 3": Will be output when selected as
input source of Zone 3 playback
"Main/Zone 3": Will be output when selected
as input source of main room or Zone 3
playback
"Zone 2/Zone 3": Will be output when selected
as input source of Zone 2 or Zone 3 playback
"Main/Zone 2/Zone 3": Will be output when
selected as input source of main room, Zone
2 or Zone 3 playback
