Integra DRX-2.1 - Page 59

27
> Network Functions > Specifications > Advanced Setup > Listening Modes
Troubleshooting Supplementary Information, etc�|
> Basic Manual
Setting Item Default Value Setting Details
AUX Zone 2
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
AUX
" is selected as input for
main room
.
"Zone 2": Output when "
AUX
" is selected as input
for ZONE2.
"Main/Zone 2": Output when "
AUX
" is selected as
input for main room or ZONE2
.
CD Zone 2
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
CD
" is selected as input for
main room.
"Zone 2": Output when "
CD
" is selected as input for
ZONE2.
"Main/Zone 2": Output when "
CD
" is selected as
input for main room or ZONE2
.
TV Zone 2
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
TV
" is selected as input for
main room.
"Zone 2": Output when "
TV
" is selected as input for
ZONE2.
"Main/Zone 2": Output when "
TV
" is selected as
input for main room or ZONE2
.
PHONO Zone 2
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
PHONO
" is selected as input
for main room.
"Zone 2": Output when "
PHONO
" is selected as
input for ZONE2.
"Main/Zone 2": Output when "
PHONO
" is selected
as input for main room or ZONE2
.
Setting Item Default Value Setting Details
TUNER Zone 2
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
TUNER
" is selected as input
for main room.
"Zone 2": Output when "
TUNER
" is selected as
input for ZONE2.
"Main/Zone 2": Output when "
TUNER
" is selected
as input for main room or ZONE2
.
NET Zone 2
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
NET
" is selected as input for
main room.
"Zone 2": Output when "
NET
" is selected as input
for ZONE2.
"Main/Zone 2": Output when "
NET
" is selected as
input for main room or ZONE2
.
BLUETOOTH Zone 2
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
BLUETOOTH
" is selected as
input for main room.
"Zone 2": Output when "
BLUETOOTH
" is selected
as input for ZONE2.
"Main/Zone 2": Output when "
BLUETOOTH
" is
selected as input for main room or ZONE2
.
■ 7� 12V Trigger C
Set when outputting the control signal (maximum 12 V/25 mA) through the 12V TRIGGER
OUT C jack. Different settings can be set for each input selector. You can enable power link
operation when you connect the unit and the external devices equipped with 12V trigger
input jack.
