3/41 PAGE
EV
F901 or FUSE 6A-T/UL-ST2 (1) 252259GR
!
EV
F903 FUSE 5A-UL/T-233 1 252326GR
!
EV
F903 or FUSE 5A-T/UL-ST2 (1) 252258GR
!
EV
F911 FUSE 8A-UL/T-233 1 252329GR
!
EV
F911 or FUSE 8A-T/UL-ST2 (1) 252261GR
!
EV
F912 FUSE 8A-UL/T-233 1 252329GR
!
EV
F912 or FUSE 8A-T/UL-ST2 (1) 252261GR
!
EV
F913 FUSE 3.15A-UL/T-233 1 252323GR
!
EV
F913 or FUSE 3.15A-T/UL-ST2 (1) 252256GR
!
EV
P704 FFC NCFC7-131012 1 2047131012
EV
P715 FFC NCFC7-272012 1 2047272012
EV
Q521 TR 2SC5200-O 1 2202823
!
EV
Q521 or TR 2SC5200-R (1) 2202822
!
EV
Q521A ISO SHEET AC262 4 223025
!
EV
Q522 TR 2SC5200-O 1 2202823
!
EV
Q522 or TR 2SC5200-R (1) 2202822
!
EV
Q523 TR 2SA1943-O 1 2202813
!
EV
Q523 or TR 2SA1943-R (1) 2202812
!
EV
Q524 TR 2SA1943-O 1 2202813
!
EV
Q524 or TR 2SA1943-R (1) 2202812
!
EV
<Note>
EV
Must use the same HFE rank mutually about the following parts.
EV
Ref. No. : Q521 - 524
EV
D911 DIODE D10XB60H 1 22380337
!
EV
T901 P TRANS NPT-1575D 1 2301943
!
EV
U01 AMPLIFIER PC board ass'y NAAF-9610-1A 1 1B226510-1A
EV
U02 TONE CONTROL PC board ass'y NAAF-9611-1A 1 1B226511-1A
EV
U03 RECTIFIER PC board ass'y NAPS-9612-1A 1 1B226512-1A
EV
U04 HOLDER PC board NAETC-9613-1A 1 ---
NSP
EV
U05
TRANS. SEC. TERMINAL PC board ass'y
NAPS-9614-1A 1 1B226514-1A
EV
U07 MICROPROCESSOR PC board ass'y NADG-9619-1A 1 1B226519-1A
EV
U08 DISPLAY PC board ass'y NADIS-9620-1A 1 1B226520-1A
EV
U09 THERMAL SENSOR PC board ass'y NAETC-9621-1A 1 ---
NSP
