4/41 PAGE
EV
U10 HOLDER PC board NAETC-9622-1A 1 ---
NSP
EV
U11 POWER SUPPLY PC board ass'y NAPS-9623-1A 1 1B226523-1A
EV
U12
TRANS. PRI. TERMINAL PC board ass'y
NAETC-9624-1A 1 ---
NSP
EV
U13 INLET PC board ass'y NAETC-9625-1A 1 ---
NSP
EV
U14 VOLUME PC board ass'y NAETC-9626-1A 1 ---
NSP
EV
U15 VIDEO PC board ass'y NAVD-9627-1A 1 1B226527-1A
EV
U16 HEADPHONE JACK PC board ass'y NAETC-9628-1A 1 ---
NSP
EV
U17 ZONE 2/ XM PC board ass'y NAAR-9631-1A 1 1B226531-1A
EV
U28 TUNER UNIT FAE385-A11US 1 240152
EV
U28 or TUNER UNIT ENG06507QFUS (1) 240156
DTM-5.9
PC BOARD PARTS LIS
PCB1
U01
AMPLIFIER PC BOARD (NAAF-9610-1A)
PCB1
U02
TONE CONTROL PC BOARD (NAAF-9611-1A)
PCB1
U03
RECTIFIER PC BOARD (NAPS-9612-1A)
PCB1
U05
TRANS. SEC. TERMINAL PC BOARD (NAPS-9614-1A)
PCB1
PCB1
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PCB1
Q301 IC NJM4558D-X 1 222502
PCB1
Q302 IC R2S15211FP 1 22242297R3
PCB1
Q361 TR 2SC1815-GR 1 2211255T
PCB1
Q362 TR 2SA1015-GR 1 2211455T
PCB1
Q401 IC NJM2068L-D 1 22240250
PCB1
Q403 IC NJM2068L-D 1 22240250
PCB1
Q452 TR DTC123JS 1 2213640T
PCB1
Q452 or TR KRC105M (1) 2215830T
PCB1
Q491 TR RN1241-A(TPE4_F) 1 2213631T
PCB1
Q491 or TR RN1241-B (1) 2213632T
PCB1
Q492 TR RN1241-A(TPE4_F) 1 2213631T
PCB1
Q492 or TR RN1241-B (1) 2213632T
PCB1
Q493 TR KRA102M 1 2215770T
