Model No: 3390 Drawring No:
Customer :
Title
M-490 Plus
Rev,Date:
Frequencies Tables for M-790 Plus
Specification LCD Display
Legal Bands
Italy 40CH AM / FM 4W
IO
Italy 36CH AM / FM 4W
I2
Germany 80CH FM 4W 12CH AM 1W
DE
Germany 40CH FM 4W 12CH AM 1W
D2
Europe 40CH FM 4W 40CH AM 1W
EU
CEPT 40CH FM 4W
CE
Spain 40CH AM / FM 4W
SP
France 40CH FM 4W 40CH AM 1W
FR
England 40CH FM 4W English Frequencies + EC 40CH FM 4W CEPT
UK
Poland 40CH AM / FM 4W Polish Frequencies –5kHz
PL
EXPORT Bands
Russia 400CH AM / FM 4W
RU
Poland 400CH AM / FM 4W Polish Frequencies –5kHz
PO
Private Channels AM / FM 4W
PC
**Sweden 24CH FM 4W (31MHz) **Sweden Band won’t be work
SW
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 26 / 61
