Intek M-490 Plus - Page 37

Model No: 3390 Drawring No:
Customer :
Title
M-490 Plus
Rev,Date:
No. Part No. Part name & Description Q’ty
Ref.
28 252-327-0 LCD DISPLAY IS06618P 1 LCD1
29 431-162-1Z SW SLIDE SKS-22021T 2 SW9.11
30 436-059-7Z SW TACT TM115AP 10 SW1.2.3.4.5.6.7.8.10.12
31 533-90M-A MIC ASS'Y 1
32 002-104-1Z FILM RESISTOR 100K 1/ 8W 5% ST 1 R70
33 002-154-6Z FILM RESISTOR 150K 1/ 8W 5% ST 1 R69
34 002-473-4Z FILM RESISTOR 47K 1/ 8W 5% ST 1 R23
35 411-803-A P.C.B MIC 16.9 X33.5 X1.6 XPC-94HB 1/0 1
36 420-233-5 MIC CARTRIDGE FDM-600M 1 MIC1
37 420-340-7Y CORD CURLED STHK-23063 1
38 421-069-8 MIC CONNECTOR MIC-6PIN(P) SW-1561 1 J106
39 432-040-6 SW PUSH SPPH221AP011 1 SW406
40 432-058-3Y PUSH SWITCH SKPS-2210C 1 SW102
41 436-059-7Z SW TACT TM115AP 2 SW103.104
42 533-90M-BA MAIN BODY ASS'Y 1
43 504-892 MOLEX PLUG ASS'Y 1
44 533-90M-PA MAIN PCB AUTO ASS'Y 1
45 05B-000-5Z CHIP RESISTOR 0 1/16W 5% T 1608 3 R3.11.68
46 05B-100-2Z CHIP RESISTOR 10 1/16W 5% T 1608 1 R34
47 05B-101-3Z CHIP RESISTOR 100 1/16W 5% T 1608 10 R36.47.104.109.139.152.276.
447.601.612
48 05B-102-4Z CHIP RESISTOR 1K 1/16W 5% T 1608 11 R5.35.38.101.105.106.226.412.
416.425.605
49 05B-103-5Z CHIP RESISTOR 10K 1/16W 5% T 1608 18 R22.27.28.32.46.117.142.171.
228.418.444.446.461.462.603. +
607.610.56
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 39 / 61
