Intek M-490 Plus - Page 39

Model No: 3390 Drawring No:
Customer :
Title
M-490 Plus
Rev,Date:
No. Part No. Part name & Description Q’ty Ref.
72 05B-393-0Z CHIP RESISTOR 39K 1/16W 5% T 1608 3 R155.407.442
73 05B-470-6Z CHIP RESISTOR 47 1/16W 5% T 1608 3 R27A.128.306
74 05B-471-7Z CHIP RESISTOR 470 1/16W 5% T 1608 8 R1.24.25.31.112.213.311.427
75 05B-472-8Z CHIP RESISTOR 4.7K 1/16W 5% T 1608 7 R131.143.144.236.303.304.439
76 05B-473-9Z CHIP RESISTOR 47K 1/16W 5% T 1608 13 R9.14.19.146.178.272.273.274.
275.435.437.441.902
77 05B-474-0Z CHIP RESISTOR 470K 1/16W 5% T 1608 4 R33.49.608.613
78 05B-475-1Z CHIP RESISTOR 4.7M 1/16W 5% T 1608 1 R434
79 05B-479-5Z CHIP RESISTOR 4.7 1/16W 5% T 1608 1 R308
80 05B-561-5Z CHIP RESISTOR 560 1/16W 5% T 1608 3 R55.148.611
81 05B-563-7Z CHIP RESISTOR 56K 1/16W 5% T 1608 3 R102.175.413
82 05B-681-0Z CHIP RESISTOR 680 1/16W 5% T 1608 2 R39.609
83 05B-682-1Z CHIP RESISTOR 6.8K 1/16W 5% T 1608 3 R30.305.405
84 05B-683-2Z CHIP RESISTOR 68K 1/16W 5% T 1608 1 R602
85 05B-822-1Z CHIP RESISTOR 8.2K 1/16W 5% T 1608 1 R2
86 05B-823-2Z CHIP RESISTOR 82K 1/16W 5% T 1608 1 R53
87 05B-824-3Z CHIP RESISTOR 820K 1/16W 5% T 1608 1 R138
88 130-A47-3 CHIP CERAMIC 0.0012UF GRM39 X7R122J 50V PT 1 C316
89 130-A73-6Y CHIP CERAMIC 0.01UF GRM39 X7R103K 25V 35 C10.22.24.47.102.105.106.112.
120A.129.137.138.139.149.217.+
227.231.234.236.241.256.302.
304.308.424.427.438.443.503.
531.532.612.616.26.31
90 130-A75-8Y CHIP CERAMIC 0.001UF GRM39 X7R102K 50V PT 7 C37.115.144.221.226.442.446
91 130-B09-9Y CHIP CERAMIC 0.1UF GRM39 X7R104K 16V AT 21 C8.17.122.127.128.136.142.152
.177.178.204.208.215.451.453.+
458.602.613.614.615.135
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 41 / 61
