Intek M-490 Plus - Page 48

Model No: 3390 Drawring No:
Customer :
Title
M-490 Plus
Rev,Date:
TRANSISTOR
Ref. Pin TX RX Ref. Pin TX RX
Q202 E 0 0 Q303 E 0 0
KRC102 C 0 0 2SC2314 C 7.8 4.5
B 4.3 4.3 B 0 0
Q204 E 0 0 Q304 E 0 0
KTC3876 C 0.3 0.3 2SC2078 C 12 4.5
B 0 0 B 0 0
Q205 E 3.6 0 Q403 E 0 0
KTA1504 C 0 0 KRC101 C 0.3 0.3
B 3 0.2 B 0 0
Q207 E 0 7 Q404 E 0 0
KTC3876 C 8 8 KRC101 C 0 0
B 4.3 0 B 4 4
Q208 E 8 8 Q405 E 0 0
KTA1504 C 7.8 0 KRC101 C 0.3 0.3
B 7.1 7.8 B 0 0
Q211 E 8 8 Q406 E 0 0
KTC3876 C 11.2 12.39 KRC101 C 0 0.5
B 8.7 8.7 B 7.8 0
Q212 E 6.7 1.4 Q408 E 0 0
KRC102 C 10.8 12.4 KTC3880 C 7 7
B 7.8 0 B 4.8 4.8
Q213 E 11.5 12.5 Q409 E 0 0
KTA1504 C 1.5 11.4 KTC3876 C 1.7 0
B 10.7 12.4 B 0 0.7
Q214 E 12.3 12.9 Q411 E 0 0
KTB1367 C 11 1.4 KTC3880 C 3.5 3.5
B 11 12.6 B 0.8 0.8
Q215 E 7.1 7.1 Q412 E 0 0
KTC3876 C 8 8 KTC3880 C 3.4 3.4
B 7.8 7.8 B 0.7 0.7
Q301 E 1.2 0 Q415 E 5 5
KTC3880 C 8 0 KTC3876 C 12.8 12.8
B 1.9 0 B 5.6 5.6
Q302 E 0.8 0 Q418 E 0 0
KTC3880 C 7.8 0 KRC101 C 0 0
B 1.3 0 B 2.7 2.7
Created by: Approved by: Rev.No:
For Stage: Release Date: Page: 50 / 61
