Intel 8086 User Manual

8086
A.C. CHARACTERISTICS (Continued)
TIMING RESPONSES
Symbol Parameter
8086 8086-1 8086-2
Units
Test
Min Max Min Max Min Max
Conditions
TCLAV Address Valid Delay 10 110 10 50 10 60 ns
TCLAX Address Hold Time 10 10 10 ns
TCLAZ Address Float TCLAX 80 10 40 TCLAX 50 ns
Delay
TLHLL ALE Width TCLCH-20 TCLCH-10 TCLCH-10 ns
TCLLH ALE Active Delay 80 40 50 ns
TCHLL ALE Inactive Delay 85 45 55 ns
TLLAX Address Hold Time TCHCL-10 TCHCL-10 TCHCL-10 ns
TCLDV Data Valid Delay 10 110 10 50 10 60 ns *C
L
e
20–100 pF
for all 8086
TCHDX Data Hold Time 10 10 10 ns
Outputs (In
addition to 8086
TWHDX Data Hold Time TCLCH-30 TCLCH-25 TCLCH-30 ns
selfload)
After WR
TCVCTV Control Active 10 110 10 50 10 70 ns
Delay 1
TCHCTV Control Active 10 110 10 45 10 60 ns
Delay 2
TCVCTX Control Inactive 10 110 10 50 10 70 ns
Delay
TAZRL Address Float to 0 0 0 ns
READ Active
TCLRL RD Active Delay 10 165 10 70 10 100 ns
TCLRH RD Inactive Delay 10 150 10 60 10 80 ns
TRHAV RD Inactive to Next TCLCL-45 TCLCL-35 TCLCL-40 ns
Address Active
TCLHAV HLDA Valid Delay 10 160 10 60 10 100 ns
TRLRH RD Width 2TCLCL-75 2TCLCL-40 2TCLCL-50 ns
TWLWH WR Width 2TCLCL-60 2TCLCL-35 2TCLCL-40 ns
TAVAL Address Valid to TCLCH-60 TCLCH-35 TCLCH-40 ns
ALE Low
TOLOH Output Rise Time 20 20 20 ns From 0.8V to 2.0V
TOHOL Output Fall Time 12 12 12 ns From 2.0V to 0.8V
NOTES:
1. Signal at 8284A shown for reference only.
2. Setup requirement for asynchronous signal only to guarantee recognition at next CLK.
3. Applies only to T2 state. (8 ns into T3).
16

Intel 8086 Specifications

General

Architecture	x86
Clock Speed	5 MHz to 10 MHz
Data Width	16-bit
Address Bus Width	20-bit
Transistor Count	29, 000
Instruction Set	x86
Package	40-pin DIP
Microarchitecture	8086
Addressable Memory	1 MB
Manufacturing Process	3 μm
Voltage	+5V
Introduced	1978
Registers	14 registers (including segment registers)
