Intel 945GC - Specification

3
1-2 Specification
Spec Description
Design
∗ Micro ATX form factor 4 layers PCB size: 24.4*21.0cm
Chipset
∗ Intel 945GC Memory Controller Hub (MCH) Chipset
∗ Intel 82801GB I/O Controller Hub (ICH7) Chipset
CPU Socket
(LGA775 )
∗
Support Intel Pentium 4, Celeron D, Pentium D, and Core 2 Duo 775-Land
LGA Package utilizes Flip-Chip Land Grid Array (FCLGA) package processor
∗
Support FSB Frequency 1333/1066/800MHz or FSB Frequency 800/533MHz
Memory Socket
∗
240-pin DDR2 RAM module socket x 2
∗
Support Dual channel DDR2 400/DDR2 533/DDR2 667 MHz RAM Module
and which is expandable to 2.0GB.
Expansion Slots
∗
PCI-Express x16 slot 1pcs delivers up to 8 GB/s of concurrent bandwidth.
∗
32-bit PCI slot x 2pcs at 133MHz
Integrate IDE and
Serial ATA2
∗
One PCI IDE controller that supports PCI Bus Mastering, ATA PIO/DMA and
the ULTRA DMA 33/66/100 functions that deliver the data transfer rate up to
100 MB/s; four Serial ATA2 ports provide 3.0 Gb /sec data transfer rate.
Integrated VGA
∗
Integrated Graphic Media Accelerator 950
∗
256-bit graphics core running at 400MHz
∗
1.6 GPixels/sec and 1.6 GTexels/sec fill rate
∗
Up to 224 MB maximum video memory
∗
Up to 4 pixels per clock rendering
Optional LAN
∗
Integrated Realtek RTL8110SC PCI 10 / 100 / 1000 LAN / RTL8100C PCI
10/100 LAN／RTL8101E-GR 10/100 PCI-E LAN chip.
∗
Support Fast Ethernet LAN function of providing 10Mb / 100Mb 1000 Mb/s
or 10Mb / 100Mb/s data transfer rate
6CH-Audio
(Option)
∗
Realtek 6-channel ALC662-GR, ALC ALC880 or ALC883 AC’97 Audio
Codec onboard
∗
Audio driver and utility included
HD 8-CH
Audio
(Option)
∗
Realtek ALC880 or ALC883 Azalia 8-channel Audio Codec integrated
∗
Support 8-channel 3D surround & Positioning Audio
∗
Audio driver and utility included
BIOS
∗
Award 4MB Flash ROM
Multi I/O
∗
PS/2 keyboard and PS/2 mouse connectors
∗
Floppy disk drive connector x1
∗
Parallel headerx1 / Serial port x1 (Optional)
∗
D-Sub 15-pin VGA Conn.
∗
Optional DVI port
∗
USB 2.0 connector x 4, headers x4 (connecting cable option)
∗
8-channel Audio connector (Line-in, Line-out, MIC/ 8CH Audio)
