Intel BLKDQ35JO - Board Components Shown in Figure 1

Product Description
13
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Descri
ption
A Front panel audio header
B Speaker
C PCI Conventional bus add-in card connector
D Battery
E PCI Express x1 connector
F PCI Express x1 connector
G Chassis intrusion header
H PCI Express x16 connector
I Back panel connectors
J Processor core power connector (2 X 2)
K Rear chassis fan connector
L LGA775 processor socket
M Intel 82Q35 GMCH
N Processor fan header
O DIMM Channel A sockets
P DIMM Channel B sockets
Q Serial port header
R Main Power connector (2 X 12)
S Front panel header
T Auxiliary front panel power LED header
U Intel 82801IDO I/O Controller Hub (ICH9DO)
V BIOS Setup configuration jumper block
W Front chassis fan header
X Serial ATA connectors [5]
Y External Serial ATA (eSATA) connector
Z Front panel USB header
AA Front panel USB header
BB Front panel USB header
CC Parallel ATA IDE connector
DD IEEE-1394a header
EE High Definition Audio Link header
