Intel BLKDQ35JO - Component-Side Connectors and Headers Shown in Figure 11

Intel Desktop Board DQ35JO Technical Product Specification
46
Table 12 lists the component-side connectors and headers identified in Figure 11.
Table 12.
Component-side Connectors and Headers Shown in Figure 11
Item/callout
from Figure 11 Descri
ption
A Front panel audio header
B PCI Conventional bus add-in card connector
C PCI Express x1 add-in card connector
D PCI Express x1 add-in card connector
E Chassis intrusion header
F PCI Express x16 add-in card connector
G Processor core power connector (2 X 2)
H Rear chassis fan header
I Processor fan header
J Serial port header
K Main power connector (2 X 12)
L Front panel header
M Auxiliary front panel power LED header
N Front chassis fan header
O Serial ATA connectors [5]
P External Serial ATA (eSATA) connector
Q Front panel USB header
R Front panel USB header
S Front panel USB header
T Parallel ATA IDE connector
U Front panel IEEE-1394a header
V High Definition Audio Link header
