Electrical Specifications
30 Datasheet
§ §
Figure 4. Differential Clock Crosspoint Specification
Figure 5. Differential Measurements
660 670 680 690 700 710 720 730 740 750 760 770 780 790 800 810 820 830 840 850
200
250
300
350
400
450
500
550
600
650
VHavg (mV)
Crossing Point (mV)
550 mV
300 mV
300 + 0.5 (VHavg - 700)
550 + 0.5 (VHavg - 700)
+150 mV
-150 mV
0.0 V 0.0V
Slew_rise
+150mV
-150 mV
V_swing
Slew _fall
Diff
