Land Listing and Signal Descriptions
Datasheet 53
C20 DBI3# Source Synch Input/Output
C21 D58# Source Synch Input/Output
C22 VSS Power/Other
C23 VCCIOPLL Power/Other
C24 VSS Power/Other
C25 VTT Power/Other
C26 VTT Power/Other
C27 VTT Power/Other
C28 VTT Power/Other
C29 VTT Power/Other
C30 VTT Power/Other
D1 RESERVED
D2 ADS# Common Clock Input/Output
D3 VSS Power/Other
D4 HIT# Common Clock Input/Output
D5 VSS Power/Other
D6 VSS Power/Other
D7 D20# Source Synch Input/Output
D8 D12# Source Synch Input/Output
D9 VSS Power/Other
D10 D22# Source Synch Input/Output
D11 D15# Source Synch Input/Output
D12 VSS Power/Other
D13 D25# Source Synch Input/Output
D14 RESERVED
D15 VSS Power/Other
D16 RESERVED
D17 D49# Source Synch Input/Output
D18 VSS Power/Other
D19 DBI2# Source Synch Input/Output
D20 D48# Source Synch Input/Output
D21 VSS Power/Other
D22 D46# Source Synch Input/Output
D23 VCCPLL Power/Other
D24 VSS Power/Other
D25 VTT Power/Other
D26 VTT Power/Other
D27 VTT Power/Other
D28 VTT Power/Other
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
D29 VTT Power/Other
D30 VTT Power/Other
E2 VSS Power/Other
E3 TRDY# Common Clock Input
E4 HITM# Common Clock Input/Output
E5 FC20 Power/Other
E6 RESERVED
E7 RESERVED
E8 VSS Power/Other
E9 D19# Source Synch Input/Output
E10 D21# Source Synch Input/Output
E11 VSS Power/Other
E12 DSTBP1# Source Synch Input/Output
E13 D26# Source Synch Input/Output
E14 VSS Power/Other
E15 D33# Source Synch Input/Output
E16 D34# Source Synch Input/Output
E17 VSS Power/Other
E18 D39# Source Synch Input/Output
E19 D40# Source Synch Input/Output
E20 VSS Power/Other
E21 D42# Source Synch Input/Output
E22 D45# Source Synch Input/Output
E23 RESERVED
E24 FC10 Power/Other
E25 VSS Power/Other
E26 VSS Power/Other
E27 VSS Power/Other
E28 VSS Power/Other
E29 FC26 Power/Other
F2 GTLREF3 Power/Other Input
F3 BR0# Common Clock Input/Output
F4 VSS Power/Other
F5 RS1# Common Clock Input
F6 FC21 Power/Other
F7 VSS Power/Other
F8 D17# Source Synch Input/Output
F9 D18# Source Synch Input/Output
F10 VSS Power/Other
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
