Land Listing and Signal Descriptions
48 Datasheet
VID_SELECT AN7 Power/Other Output
VID0 AM2 Power/Other Output
VID1 AL5 Power/Other Output
VID2 AM3 Power/Other Output
VID3 AL6 Power/Other Output
VID4 AK4 Power/Other Output
VID5 AL4 Power/Other Output
VID6 AM5 Power/Other Output
VID7 AM7 Power/Other Output
VRDSEL AL3 Power/Other
VSS A12 Power/Other
VSS A15 Power/Other
VSS A18 Power/Other
VSS A2 Power/Other
VSS A21 Power/Other
VSS A6 Power/Other
VSS A9 Power/Other
VSS AA23 Power/Other
VSS AA24 Power/Other
VSS AA25 Power/Other
VSS AA26 Power/Other
VSS AA27 Power/Other
VSS AA28 Power/Other
VSS AA29 Power/Other
VSS AA3 Power/Other
VSS AA30 Power/Other
VSS AA6 Power/Other
VSS AA7 Power/Other
VSS AB1 Power/Other
VSS AB23 Power/Other
VSS AB24 Power/Other
VSS AB25 Power/Other
VSS AB26 Power/Other
VSS AB27 Power/Other
VSS AB28 Power/Other
VSS AB29 Power/Other
VSS AB30 Power/Other
VSS AB7 Power/Other
VSS AC3 Power/Other
Table 23. Alphabetical Land
Assignments
Land Name
Land
#
Signal
Buffer Type
Direction
VSS AC6 Power/Other
VSS AC7 Power/Other
VSS AD4 Power/Other
VSS AD7 Power/Other
VSS AE10 Power/Other
VSS AE13 Power/Other
VSS AE16 Power/Other
VSS AE17 Power/Other
VSS AE2 Power/Other
VSS AE20 Power/Other
VSS AE24 Power/Other
VSS AE25 Power/Other
VSS AE26 Power/Other
VSS AE27 Power/Other
VSS AE28 Power/Other
VSS AE29 Power/Other
VSS AE30 Power/Other
VSS AE5 Power/Other
VSS AE7 Power/Other
VSS AF10 Power/Other
VSS AF13 Power/Other
VSS AF16 Power/Other
VSS AF17 Power/Other
VSS AF20 Power/Other
VSS AF23 Power/Other
VSS AF24 Power/Other
VSS AF25 Power/Other
VSS AF26 Power/Other
VSS AF27 Power/Other
VSS AF28 Power/Other
VSS AF29 Power/Other
VSS AF3 Power/Other
VSS AF30 Power/Other
VSS AF6 Power/Other
VSS AF7 Power/Other
VSS AG10 Power/Other
VSS AG13 Power/Other
VSS AG16 Power/Other
VSS AG17 Power/Other
Table 23. Alphabetical Land
Assignments
Land Name
Land
#
Signal
Buffer Type
Direction
