Land Listing and Signal Descriptions
Datasheet 61
AL18 VCC Power/Other
AL19 VCC Power/Other
AL20 VSS Power/Other
AL21 VCC Power/Other
AL22 VCC Power/Other
AL23 VSS Power/Other
AL24 VSS Power/Other
AL25 VCC Power/Other
AL26 VCC Power/Other
AL27 VSS Power/Other
AL28 VSS Power/Other
AL29 VCC Power/Other
AL30 VCC Power/Other
AM1 VSS Power/Other
AM2 VID0 Power/Other Output
AM3 VID2 Power/Other Output
AM4 VSS Power/Other
AM5 VID6 Power/Other Output
AM6 FC40 Power/Other
AM7 VID7 Power/Other Output
AM8 VCC Power/Other
AM9 VCC Power/Other
AM10 VSS Power/Other
AM11 VCC Power/Other
AM12 VCC Power/Other
AM13 VSS Power/Other
AM14 VCC Power/Other
AM15 VCC Power/Other
AM16 VSS Power/Other
AM17 VSS Power/Other
AM18 VCC Power/Other
AM19 VCC Power/Other
AM20 VSS Power/Other
AM21 VCC Power/Other
AM22 VCC Power/Other
AM23 VSS Power/Other
AM24 VSS Power/Other
AM25 VCC Power/Other
AM26 VCC Power/Other
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
AM27 VSS Power/Other
AM28 VSS Power/Other
AM29 VCC Power/Other
AM30 VCC Power/Other
AN1 VSS Power/Other
AN2 VSS Power/Other
AN3 VCC_SENSE Power/Other Output
AN4 VSS_SENSE Power/Other Output
AN5
VCC_MB_
REGULATION
Power/Other Output
AN6
VSS_MB_
REGULATION
Power/Other Output
AN7 VID_SELECT Power/Other Output
AN8 VCC Power/Other
AN9 VCC Power/Other
AN10 VSS Power/Other
AN11 VCC Power/Other
AN12 VCC Power/Other
AN13 VSS Power/Other
AN14 VCC Power/Other
AN15 VCC Power/Other
AN16 VSS Power/Other
AN17 VSS Power/Other
AN18 VCC Power/Other
AN19 VCC Power/Other
AN20 VSS Power/Other
AN21 VCC Power/Other
AN22 VCC Power/Other
AN23 VSS Power/Other
AN24 VSS Power/Other
AN25 VCC Power/Other
AN26 VCC Power/Other
AN27 VSS Power/Other
AN28 VSS Power/Other
AN29 VCC Power/Other
AN30 VCC Power/Other
Table 24. Numerical Land
Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
To Next Page
