Intel D102GGC2 Specification Update

Intel
®
Desktop Board D102GGC2 Specification Update
3
GENERAL INFORMATION
Basic Desktop Board D102GGC2 Identification Information
AA Revision BIOS Revision Notes
D42788-201 GC11020M.86A.1058 1-2
D42788-202 GC11020M.86A.1065 1-2
D42788-203 GC11020M.86A.1065 1-2
D42789-201 GC11020M.86A.1058 1-2
D42789-202 GC11020M.86A.1065 1-2
D42789-203 GC11020M.86A.1065 1-2
NOTES:
1. The AA number is found on a small label on the component side of the board.
2. The ATi Radeon Xpress 200 Chipset kit used on this AA revision consists of two components as follows:
Device Stepping S-Spec Numbers
RC410 Northbridge A13 N/A
IXP450 Southbridge A13 N/A

Intel D102GGC2 Specifications

General

Number of memory slots	2
Maximum internal memory	2 GB
Supported memory clock speeds	400, 533 MHz
Processor socket	LGA 775 (Socket T)
Number of SATA connectors	4
ATX Power connector (24-pin)	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Firewire (IEEE 1394) ports	0
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	micro ATX
Compatible operating systems	Microsoft Windows XP/2000
On-board graphics card	No
Parallel processing technology support	Not supported
Networking features	Fast Ethernet

Weight and Dimensions

Depth	218.44 mm
Width	243.84 mm
