Intel D2500HN Product Guide

Intel Desktop Board D2500HN Product Guide
12
Table 2. Intel Desktop Board D2500HN Components
Label Description
A Back panel connectors
B Standby power indicator
C Main power connector (2 x 12 pin)
D Processor
E SO-DIMM 1 slot
F SO-DIMM 0 slot
G Intel NM10 Express Chipset
H SATA connectors
I System fan header
J Front panel header
K Battery
L USB front panel header
M Piezoelectric speaker header
N BIOS configuration jumper block
O PCI bus connector
P S/PDIF out header
Q Front panel audio header
R USB front panel header
S Serial port header

Intel D2500HN Specifications

General

Brand	Intel
Model	D2500HN
Category	Motherboard
Language	English
