Intel NUC Board D54250WYB and Intel NUC Board D34010WYB
Technical Product Specification
16
Table 3. Components Shown in Figure 2
Item from
Figure 2 Description
A Back panel connectors
B PCI Express Full-Mini Card connector
C PCI Express Half-Mini Card connector
D SATA 6.0 Gb/s connector
E Front panel dual-port USB 2.0 header (2.0 mm pitch)
F Front panel USB 3.0 connector
G Front panel USB 3.0 connector
H Front panel header (2.0 mm pitch)
I SATA power connector
J Front panel stereo microphone/headphone jack
K BIOS setup configuration jumper
L Consumer Infrared (CIR) sensor
M DDR3L SO-DIMM 2 socket
N DDR3L SO-DIMM 1 socket
O Internal DC power connector
