Intel D34010WYB User Manual

Technical Reference
39
2.2.3 Header (Top)
Figure 10 shows the location of the header on the top-side of the board.
Figure 11. Header (Top)
Table 12 lists the header identified in Figure 10.
Table 12. Header Shown in Figure 10
Item from Figure 11
Description
A Custom Solutions header (2.0 mm pitch)

Intel D34010WYB Specifications

General

Brand	Intel
Model	D34010WYB
Category	Motherboard
Language	English
