Intel D815EEA2 Product Guide

Intel Desktop Boards D815EEA2, D815EPEA2, D815EFV, and D815EPFV Product Guide
36
Installing a Processor
To install a processor, follow these instructions:
1. Observe the precautions in “Before You Begin” (see page 25).
2. Locate the processor socket and raise the socket handle completely (see Figure 13, B).
3. Aligning the pins of the processor with the socket, insert the processor into the socket
(see Figure 13, A and C).
4. Close the handle completely (see Figure 13, D).
OM11639
C
A
B
D
Figure 13. Installing the Processor in the Processor Socket
