Intel D815EEA2 Product Guide

Technical Reference
83
Add-In Board and Peripheral Interface Connectors for the D815EEA2 and
D815EPEA2 Boards
Figure 31 shows the add-in board and peripheral interface connectors.
OM11641
KJ
CB F G HE
1
2
33
34
1
2
40
39
1
2
40
39
I
A D
Item Description Item Description
A CNR (optional) G AGP
B PCI slot 5 H DVO (D815EEA2U only)
C PCI slot 4 I Diskette drive
D PCI slot 3 J Primary IDE
E PCI slot 2 K Secondary IDE
F PCI slot 1
Figure 31. Add-in Board and Peripheral Interface Connectors for the D815EEA2
and D815EPEA2 Boards

Intel D815EEA2 Specifications

General

Brand	Intel
Model	D815EEA2
Category	Motherboard
Language	English
