Desktop Board Features
13
Table 3. Desktop Board D945GCZ Components
Label Description
A Front panel audio header
B Serial ATA connectors
C Hi-speed USB 2.0 headers
D Main power connector (2x12)
E BIOS configuration jumper block
F PCI Express x16 connector
G PCI Express x1 connector
H PCI bus add-in card connectors
I IEEE 1394a headers (optional)
J Diskette drive connector
K Front panel header
L Front chassis fan header (3-pin, fan speed control)
M Alternate power LED header
N Processor socket
O 12 V processor core voltage connector (2x2)
P Processor fan header (4-pin, fan speed control)
Q Rear chassis fan header 1 (3-pin, fan speed control)
R IDE connector
S Chassis intrusion header
Related Links:
Go to the following links for more information about:
• Desktop board D945GCZ
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://support.intel.com/support/motherboards/desktop
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
