Intel D945GNT User Manual

Desktop Board Features
13
Table 3. Desktop Boards D945GNT Components
Label Description
A Rear fan header (4-pin, fan speed control)
B PCI Express x1 connectors
C Front panel audio header
D PCI Express x16 connector
E 12 V processor core voltage connector (2x2)
F Rear chassis fan header 1 (3-pin, fan speed control)
G Processor socket
H Processor fan header (4-pin, fan speed control)
I Main power connector (2x12)
J Diskette drive connector
K IDE connector
L Front chassis fan header (3-pin, fan speed control)
M BIOS configuration jumper
N Chassis intrusion header
O Serial ATA connectors
P Front panel header
Q Alternate power LED header
R Hi-speed USB 2.0 headers
S IEEE 1394a headers (optional)
T PCI bus add-in card connectors
