Desktop Board Features
15
Table 4. Desktop Boards D945GTP Components
Label Description
A Front panel audio header
B PCI bus add-in card connectors
C PCI Express x16 connector
D 12 V processor core voltage connector (2x2)
E Rear fan (3-pin, fan speed control)
F Processor socket
G Processor fan header (4-pin, fan speed control)
H Main power connector (2x12)
I Diskette drive connector
J IDE connector
K Front chassis fan header (fan speed control)
L BIOS configuration jumper
M Chassis intrusion header
N Serial ATA connectors
O Front panel header
P Alternate power LED header
Q Hi-speed USB 2.0 headers
R IEEE 1394 headers (optional)
S PCI Express x1 connector
Related Links:
Go to the following links for more information about:
• Desktop board D945GNT/D945GTP
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://support.intel.com/support/motherboards/desktop
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
