Intel Desktop Board D945GTP Specification Update 11
I
MPLICATION: Some PCI Express x1 add-in cards may not fully connect to PCI
Express x1 connector slot 1, due to interference between capacitors in the keep-
out zone and I/O connectors on the add-in card that are located on the I/O
bracket, in line with the edge fingers on the card.
WORKAROUND: None
STATUS: May be fixed in a later hardware revision.
Documentation Changes
The Documentation Changes listed in this section apply to the Intel
®
Desktop Board
D945GTP Technical Product Specification (Order Number D14070). All Documentation
Changes will be incorporated into a future version of that specification.
1. Change in Manufacturing Options for 8-Channel Audio S/PDIF Connectors
Section 1.1.2, Table 2, Manufacturing Options will change in its entirety as follows:
Table 2. Manufacturing Options
Audio Subsystem Intel
®
High Definition Audio subsystem in one of the following configurations:
• 8-channel (7.1) audio subsystem with five analog audio outputs and one
S/PDIF digital audio outputs (coaxial and optical) using the Sigmatel 9223
audio codec
• 6-channel (5.1) audio subsystem with three analog audio outputs using the
Sigmatel 9220 audio codec
IEEE-1394a
Interface
IEEE-1394a controller and three IEEE-1394a connectors (one back panel
connector, two front-panel connectors)
LAN subsystem
The board provides one of the following:
• Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the
Intel
®
82573E/82573V/82574V Gigabit Ethernet Controller
• 10/100 Mbits/sec LAN subsystem using the Intel
®
82562GX/82562GZ
Platform LAN Connect (PLC) device
SATA RAID
Intel
®
82801GR I/O Controller Hub (ICH7-R) for RAID support (levels 0,1,
0+1, and 5) on the SATA interface
SCSI Hard Drive
Activity LED
Connector
Allows add-in hard drive controllers (SCSI or other) to use the same LED as
the onboard IDE controller.
Trusted Platform
Module (TPM),
revision 1.2
A component that enhances platform security
