Intel Desktop Board DB65AL Technical Product Specification
12
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Twelve USB ports:
― Six USB 2.0 ports are implemented with stacked back panel
connectors (black)
― Six USB 2.0 front panel ports are implemented through three dual-port
internal headers
• Six SATA interfaces through the Intel B65 Express Chipset:
― One internal SATA 6 Gb/s port (blue)
― Three internal SATA 3 Gb/s ports (black)
― Two internal eSATA 3 Gb/s ports (red)
• One serial port header
• One PS/2* keyboard/mouse port on back panel
Legacy I/O Control
• Nuvoton* W83677HG-i Super I/O controller for hardware management and
serial port, and PS/2 support
BIOS
• Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.2
• Support for PCI Express*
• Suspend to RAM support
• Wake on Conventional PCI, PCI Express, LAN, front panel, serial, PS/2, and
USB ports
LAN Support Gigabit (10/100/1000 Mbits/s) LAN subsystem using the Intel
®
82579V Gigabit
Ethernet Controller
Expansion
Capabilities
• One PCI Express 2.0 x16 add-in card connector
• One PCI Express 2.0 x4 add-in card connector
• One PCI Express 2.0 x1 add-in card connector
• One Conventional PCI bus connector
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton Super I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Three fan sense inputs used to monitor fan activity
• Fan speed control
