Intel Desktop Board DB65AL Technical Product Specification
56
2.4 Intel
®
Management Engine BIOS Extension
(Intel
®
MEBX) Reset Header
The Intel
®
MEBX reset header (see Figure 14) allows you to reset the Intel AMT
configuration to the factory defaults. Momentarily shorting pins 1 and 2 with a jumper
(not supplied) will accomplish the following:
• Return all Intel ME parameters to their default values.
• Delete any user entered information, including PID/PPS and user entered Hash
Certificates. USB key and remote configuration data will be removed if the
parameters are not default parameters.
• Reset the Intel MEBX password to the default value (admin).
Figure 14. Intel MEBX Reset Header
Table 27. Intel MEBX Reset Header Signals
Pin Function
1 PCH.AK24 (PCH_RTCRST_PULLUP)
2 Ground
3 No connection
