Technical Reference
49
2.3 Jumper Block
CAUTION
Do not move the jumper with the power on. Always turn off the power and unplug the
power cord from the computer before changing a jumper setting. Otherwise, the
board could be damaged.
Figure 14 shows the location of the jumper block. The 3-pin jumper block determines
the BIOS Setup program’s mode. Table 28 describes the jumper settings for the three
modes: normal, configure, and recovery.
Figure 14. Location of the Jumper Block
